OS2 MMC Trunk Patchcord
3X port density compared to MPO
Precise alignment for MT-16 configurations
Low insertion loss and small diameter for space-limited installation
OS2 MMC Trunk Patch Cord
Products Description
The MMC trunk patchcord is terminated with MMC connectors, a Very Small Form Factor (VSFF) multi-fiber optical connector designed to terminate single-mode and multimode fiber cables up to 2.5mm in diameter. It employs novel TMT ferrule technology harmonized with the MT/MT-16 alignment structure. Individual connector access in the most extremely dense connector environments is easily accomplished using revolutionary DirectConec™ push-pull boot technology.
MMC has gradually become an important optical interconnection solution for CPO architecture, high-density distribution systems, and large-scale AI clusters. With MMC patch cords, data centers can simplify network management, enhance design flexibility and maximize performance and efficiency.
Key features
--Higher port density, solution to CPO
--Higher data rates and increased capacity
--Enhances EMI protection and helps improve signal integrity
--Simplifies installation and maintenance
Product Specifications
| Fiber type | Corning / YOFC, OS2 9/125nm |
| Working wavelength (nm) | 1310nm 1550nm |
| Cable outside diameter (mm) | 2.5mm |
| Fiber counts | 16 / 24 |
| Minimum cable bend diameter | 20D / 10D |
| MMC connector IL (dB) | ≤0.35dB |
| MMC connector RL (dB) | ≥60dB |
| Polarity | Ribbonflip / Ribbon straight |
| Tensile strength (short-term) | 100N |
| Tensile strength(long-term) | 30N |
| Mating times | ≥ 50 |
| Cable length | custom |
| Operating temperature (℃) | -20 to 70℃ |
| Storage temperature (℃) | -40 to 85℃ |
Application Scenarios
• Ultra high-density structured cabling
• Data center interconnects
• High-bandwidth optical modules
• CPO (Co-packaged optics)
FAQ
Q: What is the expected loss rate for MMC connectors?
A: MMC Cable Assemblies and Adapters enable IEC Grade B insertion-loss performance of less than 0.35 dB, with an angled physical contact (APC) interface that supports superior return-loss performance of less than -60 dB.
Q: In what fiber counts are MMC solutions available?
A: MMC Cable Assemblies and Adapters are currently offered in 16- and 24-fiber TMT ferrule options.
Q: What are the advantages of MMC connectors over standard MPO/MTP connectors?
A: MMC connectors use a VSFF design to maximize the port density, enabling up to three times the cabling port density when compared with MPO/MTP connectors. This enables higher bandwidth per rack unit for multiple applications, including structured cabling, hyperscale data center connectivity, transceivers and onboard optics.
