LC To ST Singlemode Simplex Patchcord
The 9/125μm single mode fiber optic cable is suitable for enterprise network, telecom room, server farms, cloud storage networks, and any place fiber jumper cables are needed.
Introducing the LC to ST Singlemode Simplex Patchcord
Our LC to ST Singlemode Simplex Patchcord is designed to deliver unparalleled performance and reliability to meet the needs of telecommunications systems, data centers, and enterprise networks. Whether you are looking for optical interconnectivity, high-speed data transmission, or signal routing, this patchcord is the ideal solution.
Features and Benefits
Our patchcord is built to last, with a wide range of features and benefits that set it apart from the competition. Let's take a closer look.
LC Connector
Our patchcord features an LC connector on one end, which is a small, rugged connector designed for high-density applications. LC connectors use a ceramic ferrule, which provides a precise alignment of the fiber strands. This feature ensures low insertion loss, high return loss, and stable signal transmission.
ST Connector
The other end of our patchcord features an ST connector, which is a bayonet-style connector that has been widely used in telecommunications systems and data centers. ST connectors feature a spring-loaded ferrule that firmly grips the fiber, ensuring stable signal transmission.
Singlemode Simplex Patchcord
Our patchcord is a singlemode simplex patchcord, which means it has a single fiber strand for transmitting signals. Singlemode fiber is designed to carry signals over long distances, making it ideal for telecommunications systems and enterprise networks. Simplex patchcords have a single fiber core to achieve high-speed transmission.
Low Insertion Loss
Our patchcord has low insertion loss, which is essential for high-speed data transmission. Insertion loss is the amount of power lost as a signal passes through a connector, and our patchcord minimizes it to ensure maximum signal power throughout the system.
Low Return Loss
Return loss is the amount of signal reflected back into the system due to imperfections in the connector. Our patchcord reduces return loss to ensure stable signal transmission, high bandwidth, and low bit error rate.
Customizable Length
Our patchcord is customizable in length, which means you can order the exact length you need for your application. This feature enables you to optimize your system for space, efficiency, and performance.
Applications
Our LC to ST Singlemode Simplex Patchcord has a wide range of applications, including:
- Telecommunications systems
- Data centers
- Enterprise networks
- Broadband networks
- Fiber optic sensing systems
Conclusion
Our LC to ST Singlemode Simplex Patchcord is the ideal solution for demanding applications that require high-speed data transmission, reliable signal routing, and stable optical interconnectivity. With a wide range of features and benefits, our patchcord offers unparalleled performance and value for money. Whether you are an OEM, distributor, or end-user, our patchcord is a reliable and cost-effective solution for your fiber optic needs. Contact us today to learn more about our products and services.
LC to ST 9/125 Singlemode Simplex Patch Cable
LC to ST SM Simplex Patchcord, with G652D, G657A1, G657A2, and G657B3 available options. Compared with multi-mode fiber, single mode fiber patch cord is used in longer distance data transmission. Typical singlemode fiber patch cord uses yellow fiber cable. Simplex means this Fiber Patch Cord is with one core; at each end there is only one fiber connector.
Fiber Connector | LC-ST | Polishing Type | APC/UPC/PC |
Fiber Type | Single-mode | Wavelength | 1310/1490/1550nm |
Insertion Loss | ≤0.2dB | Return Loss | ≥65dB (APC); ≥55dB (UPC) |
Min Bend Radius | 10mm/30mm | Fiber Count | Simplex |
Cable Diameter | 0.9/2.0/3.0mm | Outer Jacket | PVC/LSZH/OFNP |
Tensile Strength(N) | 180N (Long Term) / 500N (Short Term) | Temperature(℃) | -40~+85 |
Product Details
LC connector (Lucent Connection, Little Connector or Local Connector) allows higher density application as it has smaller diameter. Its ferrule diameter is 1.25mm, which is half of that of ST connectors. ST connector (Straight Tip connector) is a kind of great fiber optic connectors for field installation due to their reliability and durability.
BIF (Bend Insensitive Fiber) offers greater flexibility in demanding environments than traditional fiber cable. It is typically used in data centers or any space constrained area where tight bends and flexibility are required. Bend insensitive fibers are available in both 50/125 MMF (OM3 and OM4) and 9/125 SMF.
Ceramic ferrule adopts zirconium dioxide (ZrO2) as its main material, which has good thermal stability, high hardness, high melting point, wear resistance, and high processing accuracy.
LC-ST Connectors
Bend Insensitive Fiber
CCTC Ceramic Ferrule
100% Tested Before Delivery
IL RL Test
3D Tested by Daisi
End Surface Test
Production Process
