16CH CWDM Module
16CH CWDM Module 1.In some areas where the resources of telecommunication optical cables are insufficient, the business is growing rapidly, and the expansion of optical cables is urgent and inconvenient, CWDM can use a variety of old and limited optical cables, including G.653 optical cables...
As a manufacturer in China, I am excited to introduce our latest product, the 16CH CWDM Module. This product is a high-quality fiber optic device that has been designed to allow multiple channels of communication to take place over a single fiber optic cable. It is an innovative and cost-effective solution for customers who require reliable, high-performance communication in their network.
The 16CH CWDM Module offers a variety of benefits that make it a must-have product for any business that requires high-speed data transfer. Firstly, it is an affordable alternative to traditional fiber optic communication systems, thanks to its modular design that allows customers to add or remove channels as necessary. This means businesses can design a communication system that is tailored to their needs without worrying about the cost.
Another advantage of the 16CH CWDM Module is its high performance. It is designed to support data transfer rates of up to 40Gbps, providing fast and reliable communication for businesses that require high-speed data transfer. Its low insertion loss and high channel isolation also make it a very reliable product, ensuring that network performance remains at its best.
Our 16CH CWDM Module is also designed to be easy to use. It comes with a plug-and-play design that makes installation a breeze. Customers can quickly and easily install the device with minimal effort, no need for complex settings, ensuring that businesses can get up and running with their network in no time.
Furthermore, the module is compact and easy to transport. Its small size is ideal for businesses that require communication solutions where space is at a premium. As a result, it is perfect for use in urban areas, where space is limited.
This product has numerous uses in various industries, including telecommunications, data centers, and enterprise networks. It is ideal for sending large amounts of data over long distances, making it perfect for businesses with branch offices in different locations. With this type of module, a company can link to their other office or remote location without worrying about interruptions or poor performance.
The 16CH CWDM Module is a reliable solution made of high-quality materials with superior optical characteristics. Its durability and long product life make it incredibly cost-effective. Our product is rigorously tested for quality assurance and is certified by International Federation of Inspection Agencies (IFIA) and the ISO90001, ensuring that our customers receive only the highest quality product.
In conclusion, our 16CH CWDM Module presents an excellent solution for businesses looking for reliable and cost-effective communication systems. It is an innovative product that will provide high-speed data transfer and improved network performance, making it a must-have product. With its excellent reliability, ease of use and high performance, it is the perfect solution for those who demand the very best in communication systems. We believe that you will find our product the best choice for your business's communication needs.
1.In some areas where the resources of telecommunication optical cables are insufficient, the business is growing rapidly, and the expansion of optical cables is urgent and inconvenient, CWDM can use a variety of old and limited optical cables, including G.653 optical cables that cannot be used in DWDM, and use point-to-point. It provides several times the bandwidth of the existing transmission capacity to realize the bidirectional aggregation of multiple services between two points, which has better cost performance than traditional DWDM. The expansion process of CWDM is very simple. It only needs to add a pair of CWDM devices at both ends to expand the optical cable capacity by 8 times. During the expansion process, the service interruption time is short. Smooth transitions.
2.Using CWDM, it is very easy to distinguish different users by wavelength and provide users with the specified bandwidth required, so that operators can more conveniently provide wavelength rental services.
| Parameters | Value | |
| Passband(nm） | ITU±6.5 | |
| Operating wavelength（nm） | 1260-1620 | |
| 16CH CWDM | Port | 1270/1290/1310/1330/1350/1370/1390/1410... |
| Insertion loss（dB） | <3.2 | |
| Isolation(dB) | Adjacent isolation | >30 |
| Non-adjacent isolation | >40 | |
| Ripple(dB) | 0.3 | |
| PDL(dB) | 0.2 | |
| PMD(ps) | 0.2 | |
| RL(dB) | >45 | |
| Directivity(dB) | >45 | |
| Maximum Optical power(mw) | 500 | |
| Fiber Diameter | 0.9mm | |
| Package Dimension(mm) | 180*178*44/180*178*22 | |
| Connector | LC/UPC or custom | |
| Dimension（mm） | 120*80*18 | |
| Storage temperature | -40~+80°C | |
1.Ultra low insertion loss
2.High isolation
3.Mux & demux
4.Compact size
5.High reliability
6.Epoxy-free optical path
7.Telcordia GR 1221 and GR-1209 compliant
Low insertion loss
High isolation
Reach industrial grade
1.CWDM System
2.CFP transceiver modules
3.PON network
4.Line Monitoring
Metro WDM System
PON network
Enterprise networks
CE
ISO
ROHS
The 16CH CWDM module produced by OPTICO not only implements different forms of transmission, but also minimizes the loss of the entire optical fiber link on the basis of a large amount of fiber resource savings.
OPTICO's CWDM plug-in module complies with international standards.
If interested,welcom to consult!
Tips：
Due to the Covid-19,sorry that you and our team couldn't visit each other face to face.In order to make the customers know us more,please visit our VR factory,it is just like you were really standing in our factory.
OPTICO Fiber Assembelies Production Line VR:https://www.linked-reality.com/company/15664
Why choose us?
- Our CWDM Mux Demux products are backed by a comprehensive warranty and after-sales service.
- We have established quality management system standards to implement comprehensive quality control of products to ensure that each product is of high quality and low price.
- We offer a range of customization options for our CWDM Mux Demux products, including labeling, packaging, and branding.
- Our company is developing towards the direction of 'unity, harmony, atmosphere and openness', and is committed to providing 16CH CWDM Module with quality assurance for the groups in need.
- Our CWDM Mux Demux products have proven to be highly effective in a variety of applications and industry verticals.
- As a 16CH CWDM Module manufacturing and trading company, we are recognized as one of the industry's leading companies, providing fast and reliable quality products and shipping boxes, custom packaging services.
- We offer one-year warranty on all of our CWDM Mux Demux products, allowing you to buy with confidence.
- Our company is mainly engaged in the production of conventional products and the customization of high-end 16CH CWDM Module products. Over the years, we have been fortunate to cooperate with many well-known enterprises, and the reliability is very high. We will continue to improve product quality and service and strive to become a well-known brand at home and abroad.
- We offer a wide range of CWDM Mux Demux products, each designed to meet specific customer requirements.
