8F 16F Mini Optic Fiber MTP MPO Loopback
This 8F mini Optic Fiber MTP MPO Loopback MM is designed for data centers and testing systems
Especially use within parallel optics 40 and 100G networks, female and male connectors for option.
MPO MTP loopback profile
8F 16F Mini Optic Fiber MTP MPO Loopback is a must-have unit for fiber network maintenance technicians.
Optic Fiber MTP MPO Loopbacks are superior optical component in high rate networks. In storage LANs, MPO loopbacks are also widely used to achieve high-speed data transmission and reliable fiber optic connections. It can quickly detect these potential issues through reverse testing of fiber optic connections and promptly repair them to ensure stable and reliable data transmission.
MPO loopback with different numbers of cores have different polarity channel alignment configurations. For example, an 8-core loopback is usually aligned at both ends of the connector, with the middle 4 channels empty. These configurations can be selected based on specific application requirements.
Main Features
Mini Optic Fiber MTP MPO Loopback has the following features:
1. High speed data transmission: MPO Loopback uses high-speed fiber optic transmission technology, which can support high-speed data transmission, accelerate data transmission and response speed.
2. Easy to use: MPO Loopback is easy to operate and plug in and out. Simply insert the MPO Loopback into the device to start using it.
3. Strong reliability: MPO Loopback uses high-quality fiber optic skeleton, which has good durability and tensile strength, ensuring long-term stable data transmission.
4. Low cost: MPO Loopback has a lower price and is an economical and efficient data transmission and testing solution.
Specifications
|
Fiber Type |
MM, SM |
Configuration Type |
8/16F |
|
Fiber Connector |
MPO or US Conec MTP |
Polish type |
UPC/APC |
|
Return Loss |
≥25dB |
Insertion Loss |
≤1.0dB |
|
Application |
Testing, data center |
Operation Temp |
-40 to 75°C |
Product application
In fiber optic communication systems, MPO loopbacks can ensure that optical signals are not disturbed by other light sources during transmission, ensuring signal purity and transmission quality. It can support high-density fiber optic cabling systems, ensuring efficient connections between servers and switches. In brief, 16F 8F Optic Fiber MTP MPO Loopbacks have a wide range of applications in building fiber optic ring networks, achieving signal redundancy backup, providing signal isolation protection, and fiber optic loop back testing.
